Outstanding tilth and excellent penetration
Everything you need from a direct drill, engineered into a hardy 3.6m machine.
With unbeatable contour following, trash clearance and outstanding tilth are ensured. Legendary Taege 'S' tynes provide performance rivalling larger European machinery.
Taege's DB360 Double Box Direct Drill is packed with features.
All Taege machinery is cleverly designed to have very few moving parts - everything essential for supreme performance, nothing you don't need.
Simple construction and less moving parts means that over the lifetime of a Taege machine, down time and costs due to repairs and maintenance are kept to a minimum.
Sound thinking at the start means less trouble for you over the long haul.
Standard Features
- Galvanised frame
- Powder coated seed bin
- Stainless steel fertilizer bin
- Tray for calibration
- Seed box agitator kit
- Electronic touch screen monitor
- Swivel tow eye and adjstable draw bar
- 3.6m harrow set
- LED light kit with hazard panels and safety rails
- Calibration scales
- Rear draw bar
Optional Upgrades
- Small seed inserts with high baffles
- Sponge protectors (per bin)
- Broadcasting system
- M3 microgranular hopper (gravity fed)
- Rear draw bar extension (for towing with M3 hopper)
- Rear draw bar steep angle / Gully knuckle
- Stainless steel fertilizer bin
- End tow kit
Key Benefits
- Excellent penetration
- Outstanding tilth
- Contour following
- Phasing Ram System
- Taege 'S' Tynes
- No scuffing
Specifications
| Model | UD300 | SB300 | DB300 | DB360 |
|---|---|---|---|---|
| Size | 3.0m Uni Drill | 3.0m Single Drill | 3.0m Double Drill | 3.6m Double Drill |
| Row spacing (mm) | 121 | 121 | 121 | 121 |
| Sowing width (mm) | 2888 | 2783 | 2783 | 3509 |
| Overall width (mm) | 3100 | 3100 | 3100 | 3700 |
| Overall height (mm) | 2000 | 2000 | 2000 | 2000 |
| Number of tynes | 23 | 23 | 23 | 29 |
| Number of tyne rows | 2 | 3.5 | 3.5 | 3.5 |
| Tyne row stagger (mm) | 565 | 590 | 590 | 590 |
| Seed box capacity (L) | 504 | 504 | 504 | 628 |
| Working speed (kph) | 2 - 14 | 2 - 14 | 2 - 14 | 2 - 14 |
| Tractor HP required | 65 | 85 | 85 | 100 |
| Approx. weight (kg) | 950 | 1500 | 1730 | 1950 |
