Outstanding tilth and excellent penetration
More efficient, better yield. More choice, better quality.
Strong, fully welded, hot dipped galvanised frame and brackets ensures longevity of your investment.
Tyne harrows are simple to adjust to increase and decrease downward force required for levelling.
All Taege machinery is cleverly designed to have very few moving parts - everything essential for supreme performance, nothing you don't need.
Simple construction and less moving parts means that over the lifetime of a Taege machine, down time and costs due to repairs and maintenance are kept to a minimum.
Sound thinking at the start means less trouble for you over the long haul.
Standard Features
- Galvanised frame
- Hydraulically folding and depth control
- Adjustable front draw bar angle
Optional Upgrades
- Air hopper unit
- Rear drawbar tongue
- Sweep finger harrows
- Roto crumbler
- Rear drawbar extension
- LED light kit wth hazard panels
Key Benefits
- Excellent penetration
- Galvanised frame
- Contour following
- Phasing Ram System
- Taege 'S' Tynes
- No scuffing
Specifications
| Model | CTV480 | CTV600 |
|---|---|---|
| Size | 4.8m Cultivator | 6.0m Cultivator |
| Row spacing (mm) | 122 | 122 |
| Outside tyne to tyne (mm) | 4719 | 5856 |
| Overall width (mm) | 4855 | 6300 |
| Folded width (mm) | 3000 | 3000 |
| Number of tyne rows | 4.5 | 4.5 |
| Tyne row stagger (mm) | 570 | 590 |
| Working speed (kph) | 2 - 14 | 2 - 14 |
| Tractor HP required | 120 | 140 |
